Creating the Ideal Class II Resin Restoration

Few clinicians of my vintage (Class of 1986 UW School of Dentistry) would have ever believed that composite could rival the form, function, and longevity of a cast gold restoration. Today with updated preparations, injection molding of a quality heated bulk composite (Filtek One Bulkfill, 3M), and the new Evolve Bioclear posterior matrix, it is time to begin to believe.

In this case the patient had moderate, cavitated caries on

the mesial of the 47. (FIG. 1) The patient was given local

anesthetic, then a rubber dam was placed, Bioclear Disclosing Solution was applied to the entire tooth, and then a large Diamond Wedge was placed as a pre-wedge. Pre-wedging is mission-critical for both a snug contact, and for the new objective mentioned in Figure 1, for the matrix to seat deeper in the era of injection molded, infinity-edge margins.

The new name of the game: Seat the Bioclear Matrix within 1-2 mm of the bone

Traditional posterior matrix vs Bioclear matrix

The Evolve matrix that has a definitive tooth-shaped form

rather than acting as a simple sectional matrix. Therefore,

choosing the right matrix height is key. The new Matrix

Height Indicator probe is inserted into the cavity prep,

(FIG. 2 example) then compared to visual landmarks such as the neighboring marginal ridge. For adults with some bone loss and/or when the tooth to be restored has a rubber dam clamp, 2 mm are added. In this case the cavity prep measured 6 mm deep (not shown), therefore an 8 mm blue Evolve matrix was chosen. (FIGS. 3, 4). A Twin Ring separator was placed (FIG. 5) and then a two-step injection molding was performed.

A 2-step placement was required because the cavity was deeper then 5 mm, which is the maximum depth allowed for most bulk fills. 3-point curing is also required for a full 5 mm depth of cure in the interproximal which is aided greatly by a clear matrix.

Figure 6 embodies the “gold-like” marginal integrity and

broad contact. Figure 7 radiographically demonstrates what an aggressive emergence profile, additive dentistry, and monolithic injection molded composite dentistry can achieve.

Explanation on how to use the Evolve Matrix Height Indicator

Clinical Case

Class II Restoration: Bioclear. Fig. 3
Class II Restoration: Bioclear. Fig. 4
Class II Restoration: Bioclear. Fig. 5
Class II Restoration: Bioclear. Fig. 6
Class II Restoration: Bioclear. Fig. 7

Images courtesy of Dr. David Clark
